Sorry but the product is no longer in our offer.

MaxLink 22dBi 5GHz, MikroTik RBLDF

MS-MI-LDF-22
Maxlink brings alternative to Disc and LHG units. We used the not so well known but still excellent LDF unit and developed a parabolic collar antenna with a gain of 22dBi especially for it.The unit is intended for medium distances and, thanks to the collar and radome cover, it is suitable even for ... More information

Product description

Maxlink brings alternative to Disc and LHG units. We used the not so well known but still excellent LDF unit and developed a parabolic collar antenna with a gain of 22dBi especially for it.

The unit is intended for medium distances and, thanks to the collar and radome cover, it is suitable even for harsh conditions, where it can better withstand both weather conditions and interference from other networks.

In combination with the RBLDFG-5acD, a robust device was created, suitable both for PTP connections and as a client in PTMP installations. It has gigabit Ethernet and a maximum modulation speed of 866Mbps in the 5GHz band. Thanks to the routerOS operating system with an L3 license, it brings almost unlimited setting options.

The unit is delivered disassembled for easier and safer transportation. However, according to the attached instructions, its assembly will not take more than 10 minutes, and you will only need ordinary tools for assembly - wrench No. 10 and Phillips screwdriver for assembly, wrench No. 13 for fastening to the mast.

The device can be powered by a passive POE adapter, which is NOT included in the package. It can be powered with a voltage in the range 10-30V DC. The maximum consumption is max. 8W.

Package contents:

  • (1) parabolic antenna
  • (1) radome cover
  • (1) mounting accessories
  • (1) mast holder
  • (1) RBLDFG-5acD

Specifications

Wireless features

MIMO, SISO:2 x 2
Wireless frequency:5 GHz
WiFi standards:802.11ac, 802.11n, 802.11a
Transmission speed - 5GHz [Mb/s]:866
Tx power 5GHz [dBm]:25
5GHz MIMO:2 x 2
Antenna type:Directional
Type of antenna:Built-in
Antenna gain [dBi]:22

Connectors and Interfaces

LAN speed:(1) 10/100/1000Mbps
Gigabit LAN:Yes

Power

Power over Ethernet:10 .. 30V DC
Power type:PoE
PoE type:PoE-In (only)
Max. power consumption [W]:8

Physical characteristics

Antenna design:Parabolic
Outdoor use:Yes
Design:Outdoor
Operating temperature [°C]:-40 up to 70

Hardware

CPU:IPQ-4018
CPU frequency [MHz]:716
CPU cores:1
Internal storage [MB]:16
RAM [MB]:256

Software

Operating system:RouterOS - L3
IPv6 support:Yes
Default IP address:192.168.88.1
Default login and password:admin / -
