MaxLink panel antenna 15dBi 2,4GHz, 5m H155, RSMA male

ML-PA-M15-5
The new professional parabolic antenna with a gain of 19 dBi. Excels in narrow directivity and suppression of the rear and side lobes. The heart of the parabola is made of the Andrew radiator. The antenna holder is made of galvanized steel sheet with a thickness of 3 mm for maximum strength, at the... More information
To select 3 variants

Product description

The new professional parabolic antenna with a gain of 19 dBi. Excels in narrow directivity and suppression of the rear and side lobes. The heart of the parabola is made of the Andrew radiator. The antenna holder is made of galvanized steel sheet with a thickness of 3 mm for maximum strength, at the same time allows the antenna to rotate in the range of 40 ° in the vertical direction. Each dish has VSWR measurement. RF cable length 5 m.

Specifications

Wireless features

MIMO, SISO:1 x 1
Polarization:V or H
VSWR:< 1,8
F/B ratio [dB]:25
Wireless frequency:2.4 GHz
Elevation beam width (-6dB) [°]:35
Azimuth beam width (-6dB) [°]:
Antenna type:Directional
Antenna gain [dBi]:15

Connectors and Interfaces

RF connectors:(1) RSMA male

Physical characteristics

Antenna design:Panel
RF cable length [m]:5
Designed for mast diameter [mm]:28 up to 60
Purpose:Outdoor
Material:Aluminum, UV stabilized ABS plastic
Weight [kg]:0,4
Depth [mm]:25
Width [mm]:168
Height [mm]:
