MaxLink MaxStation Mikron 924PR, 24dBi dish MIMO antenna, 5GHz, RouterOS L3, complete outdoor unit

MS-MI-924PR-D
MS-MI-924PR-D is unique outdoor unit suitable as CPE or PtP solution. Mikron unit consists of MikroTik RB911-5HnD with L3 license, with integrated wireless card with two MMCX connectors to support 802.11a/n/ac 2x2 MIMO, up to 300Mbps and very precision MaxLink MIMO parabolic antenna with 24dBi gain... More information

Product description

MS-MI-924PR-D is unique outdoor unit suitable as CPE or PtP solution. Mikron unit consists of MikroTik RB911-5HnD with L3 license, with integrated wireless card with two MMCX connectors to support 802.11a/n/ac 2x2 MIMO, up to 300Mbps and very precision MaxLink MIMO parabolic antenna with 24dBi gain and maximum adapted for the 5GHz frequency band.

For adequate performance cares QCA9882 processor running at 600MHz, 64MB RAM and 10/100Mbps Ethernet port with support passive PoE.

The platform is based on MikroTik RouterBOARD RouterOS operating system. It is a complete device with a very simple installation that can be used with Internet providers who prefer a platform MikroTik RouterOS and prefer a simple installation complete unit. Power supply units can be Ethernet over passive PoE (8 to 30V DC). The product complies with FCC and CE.

Package contains

  • Device (Antenna + RouterBOARD)
  • 10/100Mbps PoE adapter
  • Holder

Specifications

Wireless features

Tx power [dBm]:26
Wireless frequency:5 GHz
WiFi standards:802.11n, 802.11a
Transmission speed - WiFi 5GHz [Mb/s]:300
Type of antenna:Built-in
Antenna gain [dBi]:24

Physical characteristics

Design:Outdoor
Operating temperature [°C]:-40 up to 70
Depth [mm]:255
Width [mm]:420
Height [mm]:

Connectors and Interfaces

LAN speed:(1) 10/100Mbps

Power

Power over Ethernet:8 .. 30V DC
Power type:PoE
PoE type:PoE-In (only)
Max. power consumption [W]:7

Hardware

RAM [MB]:64
CPU:AR9344
CPU frequency [MHz]:600
CPU cores:1
Storage internal size [MB]:16

Software

Operating system:RouterOS - L3
Default IP address:192.168.88.1
Default login and password:admin / -
