MaxLink MaxStation Mikron 918PA-D-AC-Lite, 18dBi, complete outdoor unit

MS-MI-918PA-D-AC-Lite
Unique outdoor unit suitable for client stations and wireless PtP. The Mikron unit is made from the Mikrotik RouterBOARD RB911-5HacD with an integrated wireless miniPCI card 802.11a/n/ac 2x2 MIMO with two MMCX connectors and the MaxLink 18dBi MIMO panel antenna, the most suitable for the 5GHz frequ... More information

Product description

Unique outdoor unit suitable for client stations and wireless PtP. The Mikron unit is made from the Mikrotik RouterBOARD RB911-5HacD with an integrated wireless miniPCI card 802.11a/n/ac 2x2 MIMO with two MMCX connectors and the MaxLink 18dBi MIMO panel antenna, the most suitable for the 5GHz frequency band.

The platform is based on Mikrotik RouterBOARD with the RouterOS operating system. These are complete devices with a very simple installation that will be used by Internet providers who prefer the Mikrotik RouterOS platform and prefer simple assembly of complete units. Unit power is only possible over Ethernet over PoE. The product complies with FCC and CE.

Package contains

  • Device
  • PoE power supply
  • Holder

Specifications

Wireless features

Tx power [dBm]:26
Wireless frequency:5 GHz
WiFi standards:802.11ac, 802.11n, 802.11a
Transmission speed - WiFi 5GHz [Mb/s]:866
Type of antenna:Built-in
Antenna gain [dBi]:18

Physical characteristics

Design:Outdoor
Operating temperature [°C]:-40 up to 70
Depth [mm]:63
Width [mm]:187
Height [mm]:187

Connectors and Interfaces

LAN speed:(1) 10/100Mbps

Power

Power over Ethernet:10 .. 30V DC
Power type:PoE
PoE type:PoE-In (only)
Max. power consumption [W]:7

Hardware

RAM [MB]:64
CPU:QCA9531
CPU frequency [MHz]:650
CPU cores:1
Storage internal size [MB]:16

Software

Operating system:RouterOS - L3
Default IP address:192.168.88.1
Default login and password:admin / -
